C10MR PRO Ultra-High Frequency Handheld Facial & Aesthetic Ultrasound Scanner

The C10MR PRO is an elite 18/24 MHz ultra-high frequency handheld facial ultrasound scanner engineered specifically for aesthetic physicians, dermatologists, and plastic surgeons requiring high near-field anatomical resolution. Featuring a compact 18 x 5 mm probe footprint and an ultra-lightweight 160g design, it allows clinicians to map delicate facial blood vessels down to 1 mm in diameter across shallow depths from 10 mm to 25 mm.

Highlights

• 18 / 24 MHz Ultra-High Frequency: Highest near-field resolution designed specifically for superficial dermal and subcutaneous facial structures.

• Ultra-Compact & Lightweight (160 g): Ultra-slim 150 x 47 x 15 mm enclosure for effortless single-handed navigation across intricate facial contours.

• Facial Micro-Vessel Mapping: Resolves blood vessels down to 1 mm in diameter at depths of 10, 15, 20, and 25 mm.

• High-Density 192-Element Transducer: Paired with 64 channels to deliver sharp B-mode, Color Doppler, PDI, and PW Doppler imaging.

• IP68 Waterproof Enclosure: Fully submersible design with a dual cooling coating for reliable liquid sterilization and continuous scanning without overheating.

Description

The C10MR PRO Handheld Facial Ultrasound Scanner delivers targeted diagnostic clarity for delicate aesthetic and dermatological procedures. Operating at extreme frequencies of 18 MHz and 24 MHz with a shallow 10–25 mm depth range, it provides unmatched detail of superficial skin layers, fascia, and vascular pathways across high-risk injection zones (lips, nose, glabella, tear troughs, and jawline).

Utilizing the C10MR PRO during filler procedures allows practitioners to visualize underlying facial arteries prior to needle insertion, eliminating guesswork and drastically reducing the risk of vascular occlusion or tissue necrosis. For post-treatment complications, the scanner enables precise localization of previously injected dermal fillers and guides targeted hyaluronidase dissolution.

Equipped with dual-mode connectivity (5G Wi-Fi or direct USB cable), the scanner supports continuous operation while charging. Running on the subscription-free MY USG app (compatible with iOS, Android, and Windows), clinicians can perform real-time dual-screen comparisons, utilize measurement magnification tools, and export reports in DICOM format for seamless clinic integration.

Technical Specifications

Clinical Applications

• Pre-Injection Vascular Mapping: Locate and map facial arteries (facial, angular, superior/inferior labial, and superficial temporal arteries) prior to administering dermal fillers or neurotoxins.

• Targeted Filler Dissolution: Scan past filler treatments to evaluate product placement, detect nodules or asymmetries, and guide precise hyaluronidase injections.

• High-Precision Facial Procedures: Safe image guidance for liquid rhinoplasty, lip augmentation, jawline/chin contouring, Kybella fat reduction, and tear-trough fillers.

• Dermatology & Cutaneous Imaging: High-resolution evaluation of epidermal/dermal thickness, superficial skin lesions, and subcutaneous inflammatory conditions.

How to Use C10MR PRO

1. Download App: Install the free MY USG app from the App Store or Google Play (no subscription fees required).

2. Connect Scanner: Power on the C10MR PRO and connect your device via 5G Wi-Fi or USB cable.

3. Set Depth & Parameters: Select your anatomical focus and adjust depth parameters between 10 mm and 25 mm.

4. Scan & Map: Apply ultrasound gel to the facial zone and scan in B-mode or Color Doppler to navigate superficial micro-vessels.

5. Guide & Export: Perform targeted needle placement under live ultrasound, measure target boundaries with image magnification, and export DICOM files or video clips directly to patient files.

Frequently Asked Questions (FAQ)

How does the C10MR PRO (18/24 MHz) compare to the C10MB PRO (16/20 MHz)?

The C10MR PRO operates at higher frequencies (18/24 MHz vs 16/20 MHz), features a shallower depth range (10–25 mm vs 10–40 mm), and uses a smaller footprint (18 x 5 mm vs 24 x 6 mm). It is lighter (160 g vs 223 g), making it ideal for pinpoint near-field facial mapping.

Are there any recurring monthly app fees or software subscriptions?

No. The MY USG app is completely free to download with support for unlimited users and lifetime software updates.

Is the C10MR PRO safe for complete immersion disinfection?

Yes. It features an IP68 waterproof rating, enabling complete liquid immersion for thorough sterilization between clinical procedures.

Can I use the scanner while it is connected via USB?

Yes. The C10MR PRO supports simultaneous scanning and charging via USB cable to ensure continuous operation during long procedure days.
